AMRC-1002 (Auto & Manual)

The AMRC-1002 is a 10# automatic manual pull system specifically designed for the needs of the Lucas Oil Dirt Late Model Series. The bottle is made of aluminum, the dimensions are 18.95″ X 5.25″, and weighs 18lbs. Each AMRC has two line that would be automatically set off, one at 24″ and the other at 84″. Also has 3 Manually operated nozzles, one suggested for the cockpit and the others in the engine compartment. This bottle is SFI’d. System comes with 1.5″ roll bar mounting brackets, 5′ pull cable, and one 8′ of aluminum tubing for the manually operated nozzles.

The uses for the temperature are as follows (ALL SYSTEMS COME WITH 175 DEGREES UNLESS SPECIFIED OTHERWISE):

– 175 degree, usually used for over the fuel cell, this is the system that NASCAR uses for protection over their fuel cell.

– 200 degree, typically used for well ventilated engines, such as motorcycles. Currently sold for drag bikes mostly.

– 286 degree, used for engine bays, or area that are subjected to high heat.
